❄️ Rigid Polyurethane Panels – Premium Thermal Insulation for Demanding Applications
🧊 Multi-Type Panels: PU, PIR, PUR Sandwich Panels, Foam Boards, Cold Room Panels, Roof/Wall Insulated Panels
🌡️ Ultra-Low Thermal Conductivity: λ ≤ 0.022 W/m·K
✅ Certifications: EN 14509, ASTM C591, ISO 9001, FM Approved, CE / B2 / B-s1-d0 Fire Rating
📐 Sizes: Standard 1000–1200 mm width, lengths up to 12 m, thickness 30–200 mm
🔁 Applications: Cold rooms, prefab housing, warehouses, rooftop insulation, industrial chillers, HVAC systems
Rigid Polyurethane Panels are closed-cell foam insulation boards or sandwich panels engineered for superior thermal resistance, low water absorption, and high compressive strength. At NNRV, we supply PU and PIR panels in multiple configurations tailored to suit cold-chain logistics, commercial buildings, and energy-efficient construction.
From roof and wall panels for steel buildings to high-density PIR core panels for refrigeration and pharma, NNRV offers fire-rated, CE-marked solutions for fast installation, long life, and optimal thermal performance.
🔹 Types of Rigid PU Panels Supplied
| Panel Type | Primary Use Case | Core Type / Standard |
|---|---|---|
PU Foam Boards (Plain) | Wall/roof insulation, cavity fill | Polyurethane (PUR) – EN 13165 |
PIR Foam Panels (Rigid) | Fire-safe insulation, sandwich core | Polyisocyanurate – EN 13165 |
PU Sandwich Wall Panels | Prefab buildings, cold rooms, offices | PU/PIR Core + Color Steel Skin |
PU Roof Panels (Corrugated) | Industrial roofs, warehouses | PU Core + Galvanized Sheet Cover |
| Cold Room Insulated Panels | Refrigeration rooms, food storage | PIR Core + Antibacterial Facing |
| PU Pipe Sections (Pre-Insulated) | HVAC, hot/cold water pipelines | Rigid PU Foam + PE/Alu Jacket |
✅ λ = 0.022–0.027 W/m·K | Density: 35–45 kg/m³ | Fire Class: B2 / B-s1-d0 | Closed Cell ≥ 90%
🔹 Technical Specifications (Example – PU Sandwich Panel, 100 mm)
| Property | Specification |
|---|---|
| Thickness (core) | 100 mm |
| Panel Width | 1000 mm (effective) |
| Length | 2–12 meters (custom cut) |
| Thermal Conductivity (λ) | 0.022 W/m·K |
| Compressive Strength | ≥ 150 kPa |
| Fire Resistance (PIR option) | B-s1-d0 (EN 13501-1) |
| Facing Options | Color-coated steel, stainless, aluminum, GI |
| Joint Type | Cam-lock, tongue & groove, concealed fastener |
📋 All shipments include CE certification, TDS, MSDS, installation manual, and optional SGS/Intertek third-party inspection.
📦 Packaging & Delivery Options
| Format | 20’ FCL Load (approx.) | Ideal For |
|---|---|---|
| PU Sandwich Panels | ~250–350 m² | Cold storage, modular buildings |
| Plain PU Boards (Stacked) | ~300–500 m² | Roofs, cavity walls, underlayments |
| PU Pipe Sections (Cartoned) | ~500–1000 m lengths | HVAC and hot pipe insulation |
| PIR Fire-Retardant Panels | ~250–300 m² | Pharma, clean rooms, safety projects |
📍 Loading Ports: Hai Phong, Mundra, Istanbul, Rotterdam, Qingdao
📦 Incoterms: CIF / FOB / EXW / DDP
🔧 How It Works – Sourcing Process
1️⃣ Submit Inquiry
Specify type (PU or PIR), panel thickness, facing material, application, and delivery location.
2️⃣ Get Quotation & Technical Sheets
Receive complete quote, panel layout suggestions, performance data, and visuals.
3️⃣ Contract & Payment
Confirm via PI or supply agreement. Payment via LC, TT, or escrow.
4️⃣ Production & QA
Panels are foamed, cut, skinned, fire-tested, and packed as per specs.
5️⃣ Shipping & Support
Containerized shipping with tracking, export documents, and after-sales assistance.
✅ Why Choose NNRV for Rigid PU Panels?
❄️ Ultra-High Insulation Value: λ down to 0.022 W/m·K for superior energy savings
🔥 Fire-Safe PIR Options: B-s1-d0 rating for commercial safety compliance
🧱 High Structural Strength: Ideal for load-bearing walls, roofs, and cladding
🌍 Global Delivery Network: Export-ready with ISO, EN, and CE standards
🔧 Custom Configurations: Panel width, joint, facing, thickness as per spec
🏭 Suitable for All Climates: Anti-mold, anti-condensation, long lifespan
🏆 Client Success Story
Cold Chain Warehouse – Latin America
Supplied 8,500 m² of PIR-core insulated wall and ceiling panels with antibacterial food-safe steel facings. Reduced internal temperature variation to ±0.3°C and achieved 28% energy savings over standard EPS panels.
❓ Frequently Asked Questions (FAQs)
Q1: What’s the difference between PU and PIR panels?
PIR has higher fire resistance and slightly better thermal stability than PUR.
Q2: Can you supply ready-cut panels for cold rooms?
Yes – we can pre-cut, label, and package panels with cam-lock joints and insulation tape.
Q3: Do you offer antibacterial or food-grade facing?
Yes – stainless steel or PET laminated facings available for food/pharma projects.
Q4: What joint systems are available?
Cam-lock, concealed screw, tongue-and-groove, and clip-lock joints.
Q5: Minimum order quantity?
1×20 ft container (~250–350 m² depending on panel thickness and spec).
📩 Build Smart, Cold, and Safe with NNRV PU/PIR Panels
Let us help you construct energy-efficient, fire-rated, and thermally stable systems — from cold chains to prefabs, backed by reliable supply.
NNRV – Engineered Insulation. Delivered Globally.
